TOYOTA LANDCRUISER 79 Series –
Coil Conversion 79 Series Outback Tourer™ Release Video:
NOW AVAILABLE for Pre Registration in ALL States &
Post Registration in ALL States of Australia (Height Dependant)
Federal and State Compliance
The solution for owners/managers of Toyota Landcruiser 79 Series Ute & Dual-Cab vehicles, who have a need to carry loads to a GVM of 4000kg (up from 3300kg standard GVM), while at the same time meeting the practical and documentary compliance requirements of Work Safety, Police Licensing, Insurance, Lessor’s and Fleet Managers.
The Superior Engineering 79 series OUTBACK TOURER Upgrade Kit can be fitted to vehicles with or without Toyota’s ESC System.
WHAT DO I GET in the Superior Engineering OUTBACK TOURER™ kit?
- A true 2″ (50mm), 3″ (75mm) or 4″ (100mm) Front & Rear Suspension Lift Kit (listed below)
- Engineered to suit proper 35″ tyres on 16,17″ or 18″ wheels
- GVM increased to 3600-4000kg for 79 series
- Towing Capacity of 3500kg
- Rear axle track corrected to match the front axle (Kit Dependent)
- Heavy duty GVM compatible rear LEAF spring suspension OR
- 4 Link rear Coil Conversion for maximum articulation
- Rear Coil conversion available in Weld-on or Bolt-on
- Dual diaphragm Vacuum brake booster
- Hand brake Upgrade kit
- 2nd stage manufacture compliant – pre rego
- Legal in all states of Australia
- 1 x Compliance plate with revised GVM of up to 4000kg
- 1 x Tyre Placard (Decal) with revised axle capacities
- 1 x Vehicle Owner’s Manual
- 1 x Fitting Instruction Manual
The OUTBACK TOURER™ kit is designed to suit the following vehicles;
WHAT IS INCLUDED IN THE SUSPENSION KIT?
- Your Choice of Billet Bis80 Radius arm styles:
- Billet Radius – Lifetime Warranty Against Bending
- Superior SuperFlex – Lifetime Warranty Against Bending
- Superior HyperFlex – Lifetime Warranty Against Bending
- Superior Engineering Comp Spec TieRod – Lifetime Warranty Against Bending
- Superior Engineering Comp Spec DragLink – Lifetime Warranty Against Bending
- Superior Engineering Front Panhard Rod – Lifetime Warranty Against Bending
- Your Choice of rear suspension styles:
- Heavy Duty Superior Leaf Spring
- Rear Coil Springs
- Rear Superior Coil Conversion available in Weld-on or Bolt-in
- Side Chassis Brace
- Sway Bar Kit
- Upper Control Arm Mounts (Diff and Chassis)
- Lower Control Arm Fixed Pins
- Lower Control Arm/Shock Mount
- Coil Tower/Bracing
- Upper Adjustable Control Arms – Lifetime Warranty Against Bending
- Lower Control Arms – Lifetime Warranty Against Bending
- Front Coil Springs
- Rear Coil Springs
- Front Superior Remote Reservoir Shocks
- Rear Superior Remote Reservoir Shocks
- Superior Engineering Remote Reservoir Mounts
- Superior IFP Steering Damper
- Legendex Exhaust to a value of $1700
- Legal in all states of Australia
IS THERE ANY EXTENDED WHEEL BASE OPTIONS FOR THE OUTBACK TOURER™ KIT?
Yes, we offer a Superior 300mm Chassis Extension when having this kit fitted as seen on the All 4 Adventures 79 Series. Please discuss this with our sales representative when ordering.
WHAT BRAKE UPGRADES ARE INCLUDED IN THE KIT?
- Superior Engineering Upgraded Brake Booster
- Superior Engineering Handbrake Upgrade
- Front Braided Brake Lines
- Rear Braided Brake Lines
- Handbrake Relocation Bracketry
HOW MUCH LIFT DOES THE VEHICLE ACTUALLY GET?
The Coil /Coil or Coil / Leaf spring package will give owners a true 2″, 3″ or 4” of vehicle lift. This lift is generally done at the vehicles Tare weight and as such will be at 2″, 3″ or 4” during the most common everyday loaded condition. Spring ratings are done to ensure they will carry the additional capacity that the GVM will provide. A shock absorber package is carefully matched to provide the Maximum amount of wheel travel for that given lift height. Rigorous testing and tuning has been done to ensure amazing handling both on and offroad in all conditions.
WHAT TYRE AND RIM SIZES CAN BE RUN WITH THIS KIT?
Tires from a basic 265/70R16 up to a true 35×12.5R17 can be run in combination with rims from 16” to 18” in diameter and 0 to -25 offset. Apart from a full 35” tire the 305 and 315 metric equivalents (34.4”) can also be used legally.
Leaf Sprung 79 Series Outback Tourer™ Release Video
WHY CHOOSE A COIL CONVERSION?
While leaf springs have always been known as an economical suspension setup for carrying load and locating the diff, they are far from optimal when it comes to ride quality and offroad performance. Coils springs are available in a huge range of different heights and rates when compared to leaf springs. Coil Springs are readily available with rates to suit all applications whether you’re a heavy tourer or a 4wd carrying no weight. A coil conversion will often transform your 4wding capability as your suspension is greatly enhanced with more overall wheel travel, added traction and a comfier more controlled ride.
WHAT IS A COIL CONVERSION?
On a leaf spring vehicle the spring (leaf) also does the locating on the diff as it travels through the suspension cycle. A coil conversion replaces the factory leaf springs, shackles and bushes and replaces it with a steel fabricated crossmember that supports coil springs between the diff and chassis. The Upper and Lower control arms locate the diff as it travels through the suspension cycle, allowing the spring to do only what they do best – suspend the vehicle. Coil spring design allows the vehicle to have a wide range of spring load characteristics from soft comfy linear, dual rate for loaded and unloaded comfort or heavy duty for those that carry large constant loads. The Control arms accurately locate the diff as it travels up and down and the geometry is finely tuned to reduce dreaded rear steer and allow massive articulation while reducing tire to chassis interference. Link suspension also nearly eliminates wheel hop under acceleration which reduces load on the axles and gears.
WHICH COIL CONVERSION IS BEST FOR ME? Bolt-In or Weld-In.
The Superior Engineering rear coil conversions are available in 2 very distinct styles: Weld-in or Bolt-in. Both styles have numerous advantages and are designed around the same great platform. The Weld-in conversion ensure peace of mind that the chassis is upgraded, coated and finished any virtually eliminates the need for adjustment apart from scheduled maintenance. The Bolt-in does require visual checks at each scheduled maintenance period as a minimum, but the biggest advantage with the Bolt-in kit is the ability to remove the kit and revert to leaf springs should you ever sell the vehicle. The Bolt-in kit also allows for simple upgrades to future versions or to include optional extras at any point.
WHAT DIFFERENTIAL HOUSING IS USED TO CORRECT THE TRACK WIDTH?
Superior Engineering creates the Ultimate Landcruiser diff housing by starting with 4140 Chromoly 13.5mm wall housing tubes that are ~900Mpa average Yield Strength where our competition uses ~6mm wall carbon hollow bar that is ~470Mpa, meaning just in the tubes alone a Superior Engineering housing are almost double the strength over our competitors. FEA tests were completed with 15 tonne load on the rear axle, and even then they only showed a deflection in the housing of less than 1mm, no other brand Landcruiser housing come close!
If material strength and thickness wasn’t enough, we are also the only manufacturer using 90mm axle tubes; almost all other are still using the smaller 80mm axle tube. Utilising a 90mm axle tube greatly increases the overall strength of the housing to resist bending from excessive loading or side impacts.
Adding to this the center section of our diamond diff is fabricated as standard with 6mm high tensile 830Mpa plate! High Tensile, wear-resistant and hardened steel plate is the perfect match for the 4140 chromoly outer tubes. For added strength, it has a 4mm High Tensile Diff Guard / Skid Plate added to the rear and bottom of the housing which further protects the pinion gears and diff centre.
A massive increase in ground clearance compared to our competitors is achieved through the use of larger axle tubes and a wider overall diamond, meaning we do not have weld additional gusseting underneath the diff housing to add strength.
Overall width of the diamond center is wide and tapered, which adds an incredible increase in structural integrity and strength, the additional internal gussets of the diamond center not only help with overall strength but provide channels for oil flow aiding in cooling.
Superior Engineering is the only Australian manufacturer to use Aerospace grade – 300M axles made exclusively by RCV – ‘The manufacturer of the world toughest 4WD axles!’. These axles are the same material and hardening used in Ultra4 race cars, trophy trucks as well as an array of offroad weapons in the USA and around the world, and they are at no extra cost. The RCV 300M axles offer a lifetime warranty against breaking!
The RCV axles are attached to the housing using a billet 4340 drive plate. Factory axles are prone to break once a wheel bearing becomes loose, the use of a drive plate almost stops the fatigue caused wheel bearing play and provides a stronger overall axle drive assembly.
Our Diff upgrades kits come standard with a corrosion resistant Black powder coat finish; other optional colors are available at NO EXTRA COST! Not an additional extra like some manufacturers.
For those staying with leaf springs, we supply Billet Bisalloy 80 High Clearance U-Bolt plates as standard with our diff replacements. This gives you even more ground clearance then our competitors, added strength and support for the leaf spring pack and the tapered ends further allow the diff to slide UP and Over obstacles when offroad AND these are provided at NO EXTRA COST!
The replacement housing is
built to precise factory dimensions and the 4140 chromoly spindles, allows you
to retain all your factory brakes and bearings. OE swaybar locations are
retained on the Leaf – Replacement housing, allowing the use of factory or
aftermarket swaybars to customise the ride and handling. The finished chromoly
housing is CNC machined to accept fitment of factory locked or unlocked third
WHY DO 79 SERIES LANDCRUISER VEHICLES REQUIRE G.V.M (Gross Vehicle Mass) UPGRADES?
Real-world testing has shown that a typically fitted-out 79 Series with bull bar, winch, extra fuel tank, rear tray, canopy and a rear bar with spare wheel carrier can be easily approaching the manufacturers Original Equipment GVM of 3300/3400kg. That’s without any passengers or any luggage in the vehicle!
The Superior Engineering – OUTBACK TOURER™ kit is specifically designed to suit any vehicle owner/operator who has a need to carry loads approaching 1500 kg. All vehicles such as Loaded Tourers ,Farmers and Tradesmen, Government Departments, Mining Companies, large and small businesses can benefit from the added payload capacity. With the ever increasing possibility of litigation under common law if a vehicle is operated beyond its legal Load Limits an approved GVM increase in an almost essential upgrade.
USING SUPERIOR ENGINEERING OUTBACK TOURER™ – UPGRADE KIT, (FEDERALLY APPROVED) HELPS AVOID THESE PROBLEMS.
APPROVAL: 49878 – LC79 – 2 & 5 Seater (Single and Dual CAB – all variants)
WHAT AMOUNT OF INCREASE SHOULD YOU EXPECT?
- Officially sanctioned GVM Kit provides:
GVM to 4000kg
GVM increase of 600/700 kg
WHAT TOWING CAPACITY AM I ALLOWED?
- A Full 3500KG Braked tow capacity
- 750kg un-braked towing
Is the GCM Upgraded?
GCM (Gross Combined Mass) is used by vehicle manufacturers in sales brochures noting the combination of GVM and BTC. Please Note: The GCM (Gross Combined Mass) doesn’t form part of a Superior Engineering Approval for Second Stage Manufacture. There is currently no federal government approved test to upgrade the GCM.
It is basically governed by the new GVM of the vehicle and the maximum braked towing capacity. The original equipment maximum braked towing capacity for example on the LC79 is 3500kg. This doesn’t increase nor decrease when a Superior Engineering Outback Tourer™ Kit with GVM Upgrade is fitted, it remains at 3500kg.
The new vehicle GVM becomes 4000kg (LC79) as noted in the Superior Engineering SSM (Second Stage of Manufacture Upgrade). An important factor that must be considered is the ball weight of the towed apparatus. When towing – whatever the measured ball weight is, it must be subtracted from the vehicles GVM.
GCM is not noted or listed as part of our Approval within this vehicle Category (LC79 NB1).
Current Federal laws determine that GCM is to remain unchanged from the Original Manufacturers specifications. Some states within Australia may allow a GCM upgrade Post Registration under state laws.
WHO CAN FIT SUPERIOR ENGINEERING OUTBACK TOURER™ SUSPENSION UPGRADE KITS?
Because the Kit is approved on the basis of Superior Engineering being a Second Stage Manufacturer, and the responsibility ultimately lying with Superior Engineering, only Superior Engineering Authorised Fitters (registered Production Facilities) are approved to fit this Kit. All OUTBACK TOURER™ – Upgrade Kit’s are supplied with detailed fitting instructions and comprehensive documentation.
WHEN SHOULD AN OUTBACK TOURER™ UPGRADE KIT BE FITTED?
FEDERAL COMPLIANCE: New vehicles must be fitted prior to registration. They are simply then registered with a revised GVM, increased Lift Height and Larger Tire size range, as per the new compliance plate.
Already registered vehicles in:
NSW, ACT, VIC, SA, NT up to and including 4” Lift both DPF and Non DPF/ESC Models
QLD 2” DPF/ ESC Models or 2” and 3” Non DPF Models
WA 2” or 3” DPF/ESC and Non DPF/ESC Models
STATE COMPLIANCE: OUTBACK TOURER™ , Lift, Tire and GVM Upgrades after modification, will have to be inspected by a Superior Engineering nominated State Engineering Signatory. Extra Cost for Inspection and documents will be incurred.
